Référence : ON-EAST-1KVA

INPUT: Rated voltage: 208 / 220 / 230 / 240 Vac

Voltage range: 110 ~ 176 Vac (linear derating between 50% and 100% load ); 176 ~ 280 Vac (no derating); 280 ~ 300 Vac (derating 50%)
Frequency: 40 ~ 70 Hz (auto-sensing)
Power factor: ≥ 0.99
Bypass voltage range: - 25% ~ +15% (settable)
Total harmonic distortion (THDi) : ≤ 6%

OUTPUT: Voltage 208 / 220 / 230 / 240 Vac (settable via LCD)

Voltage regulation ± 1%
Frequency 45 ~ 55 Hz or 55 ~ 65 Hz (synchronized range); 50 / 60 Hz ± 0.1 Hz (battery mode)
Waveform Sinusoidal
Power factor 0.9
Total harmonic distortion (THDv) ≤ 2% (linear load), ≤ 5% (non-linear load)
Crest factor 3:1
Overload 105% ~ 125% for 1 min, 125% ~ 150% for 30 s, > 150% for 300 ms

Recharge time Standard model: 90% capacity restored in 3 hours; Long time   model: depend on the capacity of battery

Garantie 1 an
